Basicsforinstallingthedeviceinapipe
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  26
Configuration:
 Indirectactinggaspressureregulator(pilot‐operated)
 Withexpanderandintegratednoisereductionelement
 Outletpressuregaugewithprotectionagainstoverpressure


Configuration:
 Indirectactinggaspressureregulator(pilot‐operated)
 Indirectactingslam‐shutdevice(pilot‐operated)(two)
 Withexpanderwithoutnoisereductionelementdownstreamofthegaspressureregu‐
lator


Thenumbershavethefollowingmeaning:
No. Meaning
1 SafetyShut‐OffValve
2 Gaspressureregulator
3 Pilot
4 Safetyreliefvalve
5 Outletstopvalvearmature
6 Sensingpointforconnectionlines(grayarea)
7 Feedbackline
8 Dischargingline
9 Gaspressureregulatormeasuringline
10 Slam‐shutdevicemeasuringline
Gaspressureregulating
line‐example3
Gaspressureregulating
line‐example4
Legend
