Adjustingthesettingsofthedevice
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  41
Figure Step Description
3b
Tolowertheoperatingpressure,unscrew
thesetscrew.Adjustthescrewposition
untiltheoperatingpressureyouwantis
reached.
4
Nowsecurethesetscrew’spositionby
tighteningthehexnut(1).Important!
Makesurethatthesetscrewdoesnotturn
asyoutightenthehexnut!
5 Screwthecap(1)backon.

