Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  54
Figure Step Description
8
Unscrewthevalveplate’slocknut(1)from
below.Whiledoingso,securethevalve
shankfromabove.
9
Frombelow,removethesupportcage(1)
andthevalveplate(2).Todoso,usethe
holesinthesupportcage(3).Important!
Bothcomponentsfeaturesealingedges
thatmustnotbedamaged!
10
Pulloutthevalveshank,includingthe
compensatingplate,upward.
11
Holdtheguidebush(2)inplacefrom
below.Unscrewtheholdscrew(1).Re‐
movetheguidebush.Usearubbermallet
ifnecessary.Important!Makesurenotto
damagetheguidebush–especiallythe
sealingedges.
12
Checktheguidebush’ssealingfacefor
damage.Thesealingfacemustnothave
anyscratchesordents.Ifnecessary,
replacetheguidebushwithanewone.
