Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  55
Figure Step Description
13
Taketheguidebush.ReplacetheO‐rings
(1,2,3)withnew,lubricatedO‐rings.
14
Inserttheguidebush(2)backintothe
body.Makesureitisinitscorrectinstalla‐
tionposition.Theopeningontheside
mustpointtowardsthegasinletside.
MakesurenottodamagetheO‐rings
wheninsertingtheslidingbushing.
15
Securetheguidebush(2)withthehold
screw(1).Theholdscrewneedstobe
screwedinallthewaywithoutfail.Ifyou
areunabletoscrewtheholdscrewinall
theway,correcttheguidebush’sposition
untilyouareabletoscrewtheholdscrew
inalltheway.
16
Takethevalveshank.Removetheretaining
ring(1)belowthecompensatingplate.
17
Pullthecompensatingplate(1)downand
off. 
18
ReplacetheO‐rings(1,2)onthevalve
shankwithnew,lubricatedO‐rings.
