Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  58
Figure Step Description
29
Checkthemetalfoaminsert(1)onthe
insidefordamageandsoiling.Replaceit
withanewoneifnecessary.
30
Insertthesupportcage(1),includingthe
metalfoaminsert,backintothebodyfrom
below.
31
Insertthespringplate(2)backintothe
guidebushfromabove,makingsurethat
theplateopensupwards.Insertthe
compressionspring(1).
32 Insertthelowerdiaphragmplate(1).
33
Insertanewdiaphragm.Gluethesurfaces
tothediaphragmplateandtothebody’s
contactsurfaces.Makesurethatthebulge
pointsupwards.
