Honeywell HON R100NG Series User Manual

Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  59
Figure Step Description
34
Inserttheupperdiaphragmplate(1)and
gluethediaphragminplacethereaswell.
35
Takethesecuringrodeusedtosecurethe
diaphragm.ReplacetheO‐rings(1,2)with
new,lubricatedO‐rings.
36
Securethediaphragmunitbyscrewingin
thesecuringrodeusedtosecurethe
diaphragm(1)allthewayintothevalve
shank.Whiledoingso,securethevalve
shankfrombelow.
37
Takethebottomcover.ReplacetheO‐ring
(1)withanew,greasedO‐ring.
Skipthisstepfordeviceswithanominal
diameterof1".
38
Putthebottomcoverbackinplace.
Tightenthenuts (1)inacriss‐crossse‐
quence.
Observethetighteningtorqueinformation
providedinthetablebeforethissection.
