Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  64
Figure Step Description
40
Screwthehexnut(2)andtheupper
diaphragmplate(1)backonthepin(3).
Usethreadlockerasspecifiedinthelistin
theappendix.
41
Insertthediaphragmunit(1)backintothe
secondpressurestage’shousing.
42
Putthespringhousingbackinplace,
Tightenthescrews(1),includingthe
washers,inacriss‐crosssequence.Referto
theadditionaltighteningtorqueinfor‐
mationatthebeginningofthistopic.
43
Insertthecompressionspring(2)andthe
springplate(1)backin.
44
Takethelocknut.ReplacetheO‐rings(1,2)
withnew,lubricatedO‐rings.
