Maintenance
UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  70
Figure Step Description
20
Takethesecondpressurestage’shousing.
Turnthehousingover.Removethevalve
rod(1)andthevalverodcompression
springunderneathit(providedyouhave
notalreadysetthemasideinaprevious
step).
21 Unscrewtheguide(1)fromthehousing.
22
Removethevalve(1).Replacethevalve,
includingtheO‐ring,withanewone.Insert
thenewvalveintothehousing.
23
Taketheguide.ReplacetheO‐rings(1,2,
and3)withnew,lubricatedO‐rings.
24 Screwtheguide(1)backintothehousing.
