UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  84
No. Name 1"
Partno.
2"
Partno.
3"
Partno.
8 Diaphragm 9301004124240 8304000215410 8304000215420
21 O‐ring
8401050502136
(3units)
8401088503238
(3units)
8401117103247
(3units)
22 Slidingring
8312021368830
(2units)
8312021368840
(2units)
8312020123180
(2units)
23 Locknut 8212410100001 8212300160001 8212300200001
24 O‐ring 8401009301012 8401012402112 8401015602114
25 O‐ring 8401029703217 8401053304330 8401081904339
27 Lockingring 8236000017001 8236000022001 8236000028001
28 O‐ring 8401028302122 8401050204329 8401078704338
29 O‐ring 8401012402112 8401015503208 8401021803212
30 O‐ring
8401014001015
(2units)
8401017102115
(2units)
8401017102115
(2units)
32 O‐ring
8401020401019
(2units)
8401020401019
(2units)
8401020401019
(2units)
34 O‐ring 20419 20419 20419
41 O‐ring 8401025102120 8409043804327 8401075604337

No. Name 4"
Partno.
6"
Partno.
8"
Partno.
8 Diaphragm 8304000215430 8304000215440 8304000215440
13 Slidingring ‐ ‐ 8312020121410
21 O‐ring
8401136103253
(3units)
8401183703263
(3units)
8401240903272
(3units)
22 Slidingring
8312020123230
(2units)
8312020121330
(2units)
8312020121400
23 Locknut 8212300270001 8212300360001 8212300420001
24 O‐ring 8401023502119 8401031303218 8401037703222
25 O‐ring 8401104104346 8401151804361 8401202604369
27 Lockingring 8236000035001 8236000045001 ‐
28 O‐ring 8450097704344 8450145405435 8450196205444
29 O‐ring 8401028203216 8401037803222 8401053603227
30 O‐ring
8401021902118
(2units)
8401029902123
(2units)
8401029802123
(2units)
32 O‐ring
8401020401019
(2units)
8401020401019
(2units)
8401020401019
(2units)
34 O‐ring 8401013330000 8401013330000 8401013330000
41 Gasket 8450094604343 8450142205434 8450189805443


Billofmaterials
HONR100NG1"–3"
HONR100NG4"–8"
