UsermanualforHONR100gaspressureregulatorwithHONP095NGpilot  87
No. Name Partno.
7 Springdome 8103203133680
8 Springplate 8103004114670
9 Screw 8207160100040
10 Washer 8238093100001
11 Diaphragm 8103004112450
12 Dummyplug 8103000112330
13 Stud 8103004111840
14 Pin 8103202133690
15 Controlvalvebody 8103004111850
16 O‐ring 8401012401014
17 O‐ring 8401010801013
18 Springplate 8103004111880
19 Circlip 8236050025001
20 Hexnut 8251090080001
21 Diaphragm 8103004151780
22 Filter 8103004112130
23 O‐ring 8401006801000
24 Washer 8238093080001
25 Screw 8207160080070
26 Upstreampressurestagehousing 8611189018000
27 Controlstagehousing 8103200215950
28 Compressionspring 8501210109700
29 Controlvalve(1.0mm)hole 9303504109910
Controlvalve(2mm)hole 9303504139250
Controlvalve(3.5mm)hole 9303504141450
30 Controlvalvecompressionspring 8501220217600
31 Diaphragmplate 8103004112110
32 Restrictor 8103000114650
33 Guidebushing 8103004111900
34 O‐ring 8401031501026
35 O‐ring 8501220228900
36 O‐ring 8401004501008
37 Upstreampressurevalve 8103004133530
38 Circlip 8251437018001
39 Adjustingscrew 8103004142690
