Status Icons
Status icons appear in the up left corner of each channel display.
1:
Channel Channel number
C1
Channel
Name
User defined channel name
Search Icons
Search icons appear in the up right of each channel display.
Play Playback mode
Pause Pause search video
S
Smart Smart search mode
P
Panorama Panorama search mode
Button Index
LED Status Indicators
Power Illuminates when power is supplied to the DVR.
HDD Flashes when the hard drive is being accessed.
Record Flashes when live video is recording.
Network Illuminates when the DVR is connected to a network.
Fan Illuminates when the fan is working. Flashes when the
fan is working improperly. Unlit when the fan is not
working.
