Motion/Event Configuration
Motion / Event Configuration has four sections; Input, Sensor, Action, and
Alarm Monitor. When an event comes in (Input) the DVR records the image
according to its settings (Camera Configuration) and triggers an alarm (Action).
Input
CH – S Channels 1-8 / T Channels 9-16
MOTION – On/Off [Specify whether to use motion input or not.]
SENS (Sensitivity) – Low / Normal / High / Highest
AREA – Define the motion detection area.
SENSOR – Associate a sensor with the camera channel.
V-LOSS (Video Loss) – Select a channel to report video loss on.
MOTION/EVENT CONFIGUR ATION INPUT
INPUT SENSOR ACTION ALARM MONITOR
SAVE CANCEL
CH
T
1
2
3
4
5
6
7
8
9CH-16CH
MOTION
ON
ON
ON
ON
ON
ON
ON
ON
SENS
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
V- L OSS
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
AREA
`
`
`
`
`
`
`
`
SENSOR
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
