Honeywell HRDP DVR - Channel

Installation
______________________________________________________________________________________________
24
8 Channel
16 Channel
OUT
IN
Primary and Spot Monitor Outputs
AC Power Input
Power Switch
Network Port
RS-232 Input
VGA Output
Audio Input
S-Video Output
Audio Output
Video In Ports
Video Out Ports
Relay Output
Sensor Input
OUT
IN
Spot Monitor Outputs
Power Switch
AC Power Input
Network Port
RS-232 Input
VGA Output
Audio Input / Output
Video In Ports
Video Out Ports
Relay Output
Sensor Input
