Model IFP-2100/ECS Installation Manual LS10143-001SK-E
8-13
To exit Program Mode:
When you have completed working with the menus, press left arrow several times until you are exited from
programming mode. Two prompts will display. The first prompt is to make sure you intended to leave the panel
programming (select Yes or No as appropriate). The second prompt is for accepting all changes. If you select No,
any changes you have made since you entered panel programming will have no effect.
8.4.1.1 Moving through the Menus
Figure 8-9 shows how to move through the menu screens, using the main menu screen as an example.
Figure 8-9 Moving through Main Menu (Main Menu used as an Example)
8.4.1.2 Selecting Options and Entering Data
There are several ways to make programming selections using the control panel depending on which screen you
are currently viewing. The chart below is a generic explanation.
To Press
Select from a menu. The corresponding number on the annunciator.
Enter numeric data. The appropriate number on the annunciator.
Enter text (alphanumeric data). See Appendix B for complete list of characters.
Select from a scrolling list. The up arrow or down arrow to move through the list of available options. When the
option you want to select is displayed, press ENTER.
