SLC Modules
B200SR Sounder Base
Aux Pwr Standby: .5mA mA
Alarm: 35mA mA
SLC Standby .3 mA mA
B200S Intelligent Sounder Base
Aux Pwr Standby: .5 mA mA
Alarm: (high vol) 35 mA mA
SLC Standby .3 mA mA
B200SR-LF Low Frequency Sounder
Base
Aux Pwr Standby: 1 mA mA
Alarm: 125 mA mA
B200S-LF Low Frequency Sounder
Base
Aux Pwr Standby .55 mA mA
Alarm (high vol) 140 mA mA
SLC Standby .30 mA mA
B224RB Relay Base Standby/Alarm: 0.5 mA mA mA
RTS151/151 KEY Alarm: 7.5 mA
mA
RA100Z Alarm: 10 mA
mA
SLC Isolator Devices
SK-ISO (Isolator Module) (318 max/loop
& 2100 max/
panel)
Standby/Alarm: .45 mA mA mA
B224BI Isolator Base
Standby/Alarm: .5 mA mA mA
Accessories Modules
6815 SLC Loop Expander (63 max.) Standby/Alarm: 78 mA mA mA
RA-2000 Remote LCD Annunciator
(63 max)
4
Standby: 20 mA mA
Alarm: 25 mA mA
RA-1000 Remote LCD Annunciator
(31 max.)
Standby: 20 mA mA
Alarm: 25 mA mA
RA-100 Remote LCD Annunciator
Standby: 25 mA mA
Alarm: 50 mA mA
5824 Serial/Parallel I/O Module (4 max.) Standby/Alarm: 45 mA mA mA
5895XL Power Supply
(63 max.)
Standby/Alarm: 10 mA mA mA
5496 NAC Expander Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator
(with reset and silence switches)
63 (max.)
Standby: 35 mA mA
Alarm: 145 mA mA
5865-3 LED Annunciator
Standby: 35 mA mA
Alarm: 145 mA mA
5880 I/O Module
Standby: 35 mA mA
Alarm: 200 mA mA
5883 Relay Interface (63 max.)
Standby: 0 mA mA
Alarm: 220 mA
(22 mA per relay)
mA
ECS-50W or ECS-125W Audio
Amplifier with/without EVS-CE4
(16 max.)
Standby: 10 mA mA
Alarm: 10 mA mA
ECS-INT50W Internal Amplifier (16 max.)
Standby: 52 mA mA
Alarm @ 25V: 275 mA mA
Alarm @ 70V: 310 mA
mA
Table 3-3 Current Draw Worksheet for SK SLC Devices
Device # of Devices Current per Device
Standby
Current
Alarm
Current
