5. Set LO (Low) value, check fan speed dots, that indicates low value displayed (35 default value displayed). Use

UP/DOWN arrow button to change the value (range is 0-99).

6. Press MODE button to store the new Room ID number scrolling across the display. The unit beeps to confirm

the value is stored in memory. Once the scrolling is completed, screen display rld.

Press FAN button to move between three modes to verify the Room ID.

7. Press the FC button to return SERVICE MODE or press UP arrow button to display next mode.

Press the FC button twice to exit SERVICE MODE

Medium Value

Low Value

Main Page

Table of Contents1
E7W Smart Wall Plate (SWP) Related Issues3
- The E7W Display Shows SWP and You Can't Use the E7W3
- The E7W in a Guestroom Failed , You Have no Replacement or Spare E7W's , and You Want to Replace It with an E7W from a Different Room until You Can Obtain a New E7W5
- The E7W in a Guestroom Failed and You Want to Replace It with a New out of the Box E7W6
- Rebooting the E7W Back to Factory Default Settings7
E7W Display Related Issues8
- E7W Display Just Shows a Single Temperature Value with no Fan Speed or A/C Mode8
- The E7W Displays 2 Dashes ( - - ) and When You Try to Use the E7W There Is Only Rid , Pan and Rf Options Available8
- E7W Display Is Blank8
E7W Battery Related Issues9
- A Battery Symbol Has Appeared in the Lower Right Corner of the E7W Display in One or more Rooms9
- Occurred in IC3 or IC510
- I Replaced the Batteries in the E7W, but There Is Still a Low Battery Indication for the Room in IC3/IC510
E7W Temperature Control Related Issues12
- The E7W Is Not Controlling Room Temperature or Fan Speed12
- You Cannot Change the E7W Displayed Target Temperature, Fan Speed or HVAC Mode and a Warning Triangle Symbol Is Displayed16
- Using the E7W to Read the Status of the HVAC Controller's 5 Output Relays17
E7W Occupancy Detection Issues19
- A Room with an E7W Installed Is Constantly Reporting the Room Is Occupied in IC3/IC5 Even Though no Guest Has Been in the Room19
E7W Door Test Is Failing20
E7W PIR Motion Sensor Test Is Failing21
I am Not Able to Ping One or more Room Devices from the E7W Png (Ping) Menu22
- You Can't Ping any Room Devices from the E7W22
- You Can't Ping One or more Devices but Can Ping some Devices22
The E7W WAN (Wide Area Network) Test Is Failing24
There Is a Demanding or Important Guest that Wants to be Able to Set Room Target Temperature to a Higher or Lower Value than What Is Currently Selectable on the E7W25
Appendix 1: Setting the Room ID, PAN ID and RF Channel into the E7W During Initialization26
- Setting the Room ID During Initialization26
- Setting the PAN ID During Initialization27
- Setting the RF Channel During Initialization28
Appendix 2: Reading or Setting the Room ID, PAN ID and RF Channel into the E7W after It Has Been Initialized29
- RID - Setting E7W Room ID (Rld)29
- PAN - Setting E7W Pan ID (Pan)31
- RF - Setting E7W RF Channel (Rf)31
Appendix 3: Using the E7W Ping Feature31
Appendix 4: Using the E7W Process Image Viewer34
Appendix 5: Setting the E7W "PA" Partner Address36
Appendix 6: Using the E7W Bau (Battery Level) Parameter37
Appendix 7: Using the E7W WAN Test38
Appendix 8 : Using the E7W PING Test39
Appendix 9 : Using the E7W CBL32 Registry Viewer/Editor41
Appendix 10: Using the E7W Door Test45
Appendix 11: Adjusting the E7W PIR Motion Sensor Sensitivity47
