Honeywell Restricted

13 April 2020

Version 9.0

Value

Appendix 5: Setting the e7w “PA” Partner Address

Use PA mode to set default address used by the HVAC partner of the e7w. Any messages sent by the e7w are sent to this

Address. If the e7w HVAC partner is configured with a different address, you must change the PA value to match that

address. For example, if X47 with address 224 is used as the HVAC partner of e7w, then PA value should be changed to

224.

1. Enter SERVICE MODE

2. Press UP/DOWN arrow buttons to select PA.

3. Press MODE button. This action displays PA value (14 displayed as default PA value).

4. Use the UP/DOWN arrow buttons to change the PA value.

5. Press the FAN button to store the value. The e7w play beep sound.

6. Press the FC button to return SERVICE MODE or press UP arrow button to display next mode

Press the FC button twice to exit SERVICE MODE
