MA-2000
M-167.1-MA2000-EN / 06.2022 21
6.2.1 Terminal Board AW80US0
CNAL
DC Power Supply
1
Positive
It comes from power supply module board AW70PP1
2
Earth
3
Negative
CNB
Batteries
1
Positive Battery 1
Protection with two MFR700 series resettable fuses
2
Negative Battery 1
3
Positive Battery 2
4
Negative Battery 2
CNTH
Temperature probe
1
NTC
Batteries Temperature probe
2
GND
CNU Device Lines
01
LA1 +
Loop 1 + side A
LOOP 1
02
LA1 -
Loop 1 - side A
03
LB1 +
Loop 1 + side B
04
LB1 -
Loop 1 - side B
05
LA2 +
Loop 2 + side A
LOOP 2
06
LA2 -
Loop 2 - side A
07
LB2 +
Loop 2 + side B
08
LB2 -
Loop 2 - side B
09
+24V USR
+ 24 Vcc User
Protection with 1 A resettable electronic fuse
10
GND USR
GND User
11
RL ALL- C
Alarm Relay C
Polarity in
stand-by
Relay
contacts
30 V / 2 A
JALL Selects Potential Free NO / NC or Controlled Output
with 1 A Resettable Electronic Fuse with 47 KΩ / 5 %
Balance or Diode
12 RL ALL+ NO/NC Alarm Relay NO/NC
13
RL USR1- C
Relay USR1 C
JUSR1 selects Potential Free NO / NC or Controlled Output
with 1 A Resettable Electronic Fuse with 47 KΩ / 5 %
Balance or Diode
14 RL USR1+ NO/NC Relay USR1 NO/NC
15
RL USR2- C
Relay USR2 C
JUSR2 selects Potential Free NO / NC or Controlled Output
with 1 A Resettable Electronic Fuse with 47 KΩ / 5 %
Balance or Diode
16 RL USR2+ NO/NC Relay USR2 NO/NC
17
SIR LC +
Siren + in stand-by
Controlled Output with 1 A resettable electronic fuse
with Diode
18
SIR LC -
Siren in stand-by
19
RL GST C
Fault Relay C
Relay
contacts
30 V / 1 A
JGST Selects Free from Potential NO / NC
20 RL GST NO/NC Fault Relay NO/NC
CNS Connector 9+9 poles 2 horizontal staggered planes pitch 5
(1-9 row below 10-18 row above)
SERIAL
01
RS485H1
RS485-1 signal A+
Isolated serial RS485-1
02
GNDIS1
GND RS485-1 isolated
03
RS485L1
RS485-1 signal B-
04
RS485H2
RS232 TX2
RS485-2 A+ signal
Serial RS485-2 SW5-1,2 OFF SW5-3,4 ON
Serial RS232-2 SW5-1,2 ON SW5-3,4 OFF
05
GNDIS2
GNDIS2
GND RS485-2 isolated
06
RS485L2
RS232 RX2
RS485-2 signal B-
07
RS485H3
RS232 TX3
RS485-3 A+ signal
Serial RS485-3 SW4-1,2 OFF SW4-3,4 ON
Serial RS232-3 SW4-1,2 ON SW4-3,4 OFF
08
GNDIS3
GNDIS3
GND RS485-3 isolated
09
RS485L3
RS232 RX3
RS485-3 signal B-
10
11
12
13
CDAHA
CAN signal +
A-side CANBUS isolated
14
GNDISA
GND CANA isolated
15
CDALA
CAN signal -
16
CDAHB
CAN signal +
B-side CANBUS isolated
17
GNDISB
GND CANB isolated
18
CDALB
CAN signal -
CNBT
Communication cable for Extended PSU & Batteries
1
RS485H1
RS485-1 signal A+
Isolated RS485-1 Serial Extension
2
GNDIS1
GND RS485-1 isolated
3
RS485L1
RS485-1 signal B-
