Honeywell MA-2000 User Manual

MA-2000
M-167.1-MA2000-EN / 06.2022 43
11.2 MA-2000-0x User board (SKU 5000.00.003)
Preparation
Be sure to follow the instructions 1 – 8 under "Preparation" in chapter 11.1!
1
1
1
1
2
1. Unplug all flat cable shown in chapter 11.3.
2. Remove the 4 screws  and remove the board .
Reinstallation
3. Install the new user board on the metal plate.
4. Follow the instructions in this chapter in reverse order, then follow the preparation instructions in
chapter 11.1 in reverse order to step 8.
5. Turn on the switch from the electrical cabinet to connect the main power to the panel.
6. Plug the battery cables to the batteries and close the front panel door with the 2 screws see chapter 11.1.
Recommissioning
After completing the recommissioning, perform a complete function test of the system!
