Honeywell MA-2000 User Manual

MA-2000
26 M-167.1-MA2000-EN / 06.2022
6.4 OPTIONAL CARD
6.4.1 MA-BST-C (CAN-BUS amplifier card)
This card can be installed in a remote HLSPS25 (power supply) in the CAN-BUS network to double the distance
from node to node.
Up to 8 MA-BST-C cards can be installed in the CAN-BUS network.
DIP switch SW1 – Address Switch
Card Address
1
2
3
4
5
6
ON
OFF
OFF
OFF
OFF
OFF
Address No. 1
OFF
ON
OFF
OFF
OFF
OFF
Address No. 2
ON
ON
OFF
OFF
OFF
OFF
Address No. 3
OFF
OFF
ON
OFF
OFF
OFF
Address No. 4
ON
OFF
ON
OFF
OFF
OFF
Address No. 5
OFF
ON
ON
OFF
OFF
OFF
Address No. 6
ON
ON
ON
OFF
OFF
OFF
Address No. 7
OFF
OFF
OFF
ON
OFF
OFF
Address No. 8
CNA
N°
Description
Characteristics
Note
01
+ 24 Vcc
Power input
02
GND
03 IN GST-NO
Digital input to signalize the
power supply fault
potential-free contact
04 IN GST-C GND
CNR
N°
Description
Characteristics
Note
01
CDAHRA
Communication line (side A)
for CAN BUS NETWORK
optically isolated with 120 Ohm termination
resistor installed on board
02
GNDISRA
03
CDALRA
04
CDAHRB
Communication line (side B)
for CAN BUS NETWORK
optically isolated with 120 Ohm termination
resistor installed on board
05
GNDISRB
06
CDALRB
Can-Bus Terminal Block
Supply/Fault Terminal Block
Card Failure LED
Power LED
SW1 DIP-Switch
Rx-CAN BUS side B LED
Rx-CAN A LED
Tx-CAN BUS side A LED
Tx-CAN BUS side B LED
Fault LED Line CAN BUS-side B
Fault LED Line CAN BUS-side B
USB connector
