MA-2000
M-167.1-MA2000-EN / 06.2022 41
11 SPARE PARTS
Description Part No.
User board 5000.00.003
Flat Cables 5000.00.005
Power Supply 5000.00.007
Main board + LCD, Version 01 5000.00.010
Main board + LCD, Version 02 5000.00.011
Main board + LCD, Version 03 5000.00.012
Front door 5000.00.017
These instructions must be studied carefully and understood before the replacement of spare parts.
Any damage caused by failure to observe these instructions voids the warranty. Furthermore, no
liability can be accepted for any consequential damage arising from such failure.
Safety Information
The replacement of spare parts and recommissioning of the devices may only be carried out by
qualified electricians!
Danger – Electrical shock!
Remove all power from the panel before carrying out any installation work!
ESD protection
While handling electronic assemblies, the necessary precautions against electrostatic discharge
must be taken!
Fuses
The device fuses cannot prevent an unexpected malfunction in electrical
fuses should protect the user and his environment from damage. Therefore, never repair, bypass or
replace the factory-installed fuses with a type other than the one specified!
Protective and functional earth
The PE conductor must be connected to the corresponding terminal at the mains supply. Connect
the FE terminal of the panel’s cabinet with the protective earthing rail (PE rail) of the power
distributor panel from which the fire alarm system will be powered.
Short circuits
All voltage and signal lines must be secured with suitable fastening material, e.
fasteners so that they cannot come loose or be moved. When doing so, ensure that the power supply
line cannot touch the signal lines (SELV) when moved. Work ma
y be carried out on the fire alarm
system only when it is de-energized (mains and emergency power supply disconnected).
Recommissioning
After completing the recommissioning, perform a complete function test of the system!
