BLE (Bluetooth Low Energy) Status Indicator Icons
At the top of the screen, on the left side is the BLE icon, if the instrument is equipped with BLE.
It indicates status of the BLE, including connectivity.
Icon Explanation
BLE connected. The icon is shown when data is being
transferred.
BLE is off.
BLE is on but is not connected.
LoRa Status Indicator Icons
At the top of the screen, on the left side is the LoRa icon, if the instrument is equipped with
LoRa. It indicates status of the LoRa, including connectivity.
Icon Function
Wireless status: Radio on, no network joined or
offline
Wireless status: the radio is off
Network joined, signal very low, 0% to 24%
Network joined, signal low, 25% to 49%
Network joined, signal medium, 50% to 74%
Network joined, signal good, 75% to 100%
P2P (Point-to-Point) protocol enabled, wireless
disabled
Honeywell MultiRAE Series™ 21 User Manual
