Configuring the BACNET-GW-3 Configuration
23BACNET-GW-3 Installation and Operation Manual – P/N LS10014-000NF-E:C6 5/5/2017
3.2.3 Main Menus
The following table describes the options available in the configuration tool main menus (see Figure 3.1).
Table 3.1 Main Menus
Menu Option Description
File Reboot Reboots the BACNET-GW-3.
View Refresh Node
List
Refreshes the node list in the navigation tree.
Gateway
Activity
Opens a window that displays connection information. Used for
diagnostic purposes by technical support personnel.
Clear - Deletes the information in the activity window.
Tools Set Device
Password
Opens a dialog box allowing the user to change the current password.
Passwords are case sensitive.
Alpha and numeric characters are supported.
Eight (8) characters minimum, 64 characters maximum.
Backup... Click to download a backup file (.bkp) from the gateway to the PC
running the browser. Save or move the file to an appropriate location
so it can be used, if necessary, to restore the gateway settings.
Restore... Browse to (or search for) the backup file on the PC running the
browser. Click Open and then Send. An on-screen message indicates
a successful restoration.
Send PFX Key
File
Opens a dialog box allowing the user to upload an SSL Certificate File.
Browse for the file, enter the password (if required), and click Send.
Refer to 3.3, "Security Certificate" for additional information.
Delete Objects
Database
Opens a dialog box allowing the user to choose to delete the objects
database and reboot.
Web Portal Commission
Web Portal
Selecting this option causes the web portal to request the point
information from the FACP(s) to update the information on the eVance
server.
Unregister
Web Portal
Used prior to removing the gateway from the FACP connection.
Upgrade Firmware Opens the Send Archive File dialog box. Click the Choose File button
and select the filename that begins “BGNUW” and has the extension
“.AR”. Click Open and then click Send. An on-screen message
indicates a successful upgrade. It is recommended that the browser be
started after the upgrade.
Help Legal Displays legal information pertaining to the gateway.
About Displays software version information.
Advance
Diagnostics
Used for informational/diagnostic purposes.
