Configuration Configuring the BACNET-GW-3
26 BACNET-GW-3 Installation and Operation Manual – P/N LS10014-000NF-E:C6 5/5/2017
3.2.6 Node List
Click the desired node label in the navigation tree area of the configuration tool screen (see Figure 3.1) to
view information about that node. The information displayed is dependent on the node type. Labels for
off-line nodes display in red text.
3.2.7 Error Log
The error log displays specific information when the BACNET-GW-3 detects a problem with the web portal
connection. The following table defines the meaning of the label text.
When the error is corrected, the enrty is removed from the log and the label at the bottom of the screen
returns to its “No Errors Found” status. Information about the error is also recorded in the web portal history
log (View > History).
Node Mapping
Automatic
Mapping
• Select Yes to enable automatic mapping of the first 14 nodes the
BACNET-GW-3 discovers on the NFN network that are currently online and
monitor appropriate devices.
• Select No to disable automatic node mapping.
Show Online or
Mapped Nodes
-
Show All Nodes
The property label toggles between “Show All Nodes” and “Show Online or
Mapped Nodes” depending on the mode selected.
Select Yes to display the list of nodes in the mode indicated by the property label.
Node List An asterisked field is present to the right of the list of all nodes that the
BACNET-GW-3 can monitor. Up to 14 nodes can be monitored.
• Select Yes to enable monitoring of the node.
• Select No to disable monitoring of the node.
Note: If an “Unknown” node comes on line and is found to be of the wrong type
for the BACNET-GW-3 to monitor, its field is automatically set to “No”.
Web Portal
Setup
Configures the Web Portal feature for use with eVance. Requires the eVance user ID, password,
unique web portal name, and web portal description. Utilizes predefined customers and buildings
from eVance. Refer to 3.4, "Web Portal Setup" for additional information.
Table 3.3 Additional Properties (Continued)
Navigation Tree
Label
Property Value
Table 3.4 Error Log Label Definition
Label Description
No Errors Found
The gateway is not reporting any web portal connection errors.
# Errors Found.
Click here to view
errors.
The gateway is reporting a web portal connection error. The number of errors is
indicated in the label. Clicking the error label opens the Error Log that lists the
date, time, and a description of the error(s).
