Product Overview System Architecture
8 BACNET-GW-3 Installation and Operation Manual – P/N LS10014-000NF-E:C6 5/5/2017
1.6 System Architecture
An Internet or Intranet IP network connection is used with the architectures described in Figures 1.1 and 1.2.
Figure 1.1 Single Panel Architecture
Figure 1.2 NFN Network Architecture
BACnet/IP Client
FACP
NUP
IP Network
EthernetEthernet
BACNET-GW-3
FACP FACP
IP Network
BACNET-GW-3
FACP
BACnet/IP Client
BACnet/IP Client
HS-NCM
or
NCM
NFN Network
Ethernet Ethernet
Ethernet
