Configuration Configuring the BACNET-GW-3
24 BACNET-GW-3 Installation and Operation Manual – P/N LS10014-000NF-E:C6 5/5/2017
3.2.4 Product Information
The product information displays when initially opening the configuration tool. It can also be accessed by
clicking the first entry in the navigation tree (see Figure 3.1). After configuring the settings, click Apply in
the lower right corner of the window.
Table 3.2 Product Information
Label Property Value
BACnet
Gateway
Type Displays the gateway type by name.
Version Displays the gateway version number.
Board Type Displays the hardware model type.
Kernel Version Displays additional software version information.
Boot Version Displays additional software version information.
Current Time/Date Displays the current date and time information after the gateway
synchronizes the clock with the SNTP server.
Gateway
Properties
Notification Type Select the operating mode for the gateway from the drop-down menu:
• Multi State
• Life Safety
Network Number Enter the base network number for the gateway.
Note: If using more than one BACNET-GW-3 on the same network,
separate network numbers by at least 100.
BACnet Port Enter the port number that is used for BACNET-GW-3 communications.
Network Update
Time
Enter the time of day (24-hour format) at which the gateway will query
the network each day.
Foreign
Device
Configuration
Foreign Device
• Select Yes if the gateway will operate in Foreign Device Mode.
• Select No if the gateway will not operate in Foreign Device Mode.
IP Address Enter the IP address to be used in Foreign Device Mode.
Port Enter the value for the IP port to be used for communication in Foreign
Device Mode.
Register Time Enter the polling time (in seconds) to be used in Foreign Device Mode.
To Next Page
