Honeywell NOTIFIER BACNET-GW-3 User Manual

IP Requirements Product Overview
9BACNET-GW-3 Installation and Operation Manual – P/N LS10014-000NF-E:C6 5/5/2017
1.7 IP Requirements
1.7.1 IP Port Settings
The following IP ports must be available to the BACNET-GW-3:
1.7.2 IP Restrictions
The following IP restrictions apply to the BACNET-GW-3:
• Must have a static IP address. DHCP is not supported.
• Web access via an HTTP proxy server is not supported.
Port Type Direction Purpose
80 TCP In Web Based Configuration
443 TCP In HTTPS Communications
4016 UDP In Upgrades
47808 UDP Both BACnet

Honeywell NOTIFIER BACNET-GW-3 Specifications

General

Brand	Honeywell
Model	NOTIFIER BACNET-GW-3
Category	Gateway
Language	English
