ID3000 Series Installation & Commissioning Manual
Installation - Panel Electronics
37 997-274-000-6, Issue 6
September 2009
5.10.1 Cables and Wiring
8 Make the following cable and wiring connections to
the Enhanced Loop Interface PCB:
i Ribbon cable from socket SK2 to Base PCB socket
connector (see step 3).
ii Loop cable terminations at sockets SK3 and SK1.
