ID3000 Series Installation & Commissioning Manual
Appendix 2
A2 - 1
997-274-000-6, Issue 6
September 2009
Appendix 2 - Specifications
ID3000 Series Panel Range
General:
The Fire Control Panel meets the requirements of EN 54-2/4.
See Section 1.1 CE Marking for further details.
Mechanical:
Construction: Sheet steel enclosure with panel main
components supplied as separate
build modules. Electronic chassis
module door carries all displays and
controls under plastic fascia moulding.
Lockable, transparent user-interface
doors are optional features.
Dimensions (mm) - including moulded front cover(s):
Standard:
500(w) x 400(h) x 153(d)
Extended - standard depth:
500(w) x 620(h) x 153(d)
Extended - extra depth:
500(w) x 620(h) x 251(d)
Double-extended - standard depth:
500(w) x 840(h) x 153(d)
Double-extended - extra depth:
500(w) x 840(h) x 251(d)
Back Box Extension - standard depth:
500(w) x 220(h) x 153(d)
Back Box Extension - extra depth:
500(w) x 220(h) x 251(d).
Weights (Approx.)(no batteries):
Standard 14kg
Extended - standard depth 18kg
Extended - extra depth 20kg
Double-extended - standard depth 22kg
Double-extended - extra depth 24kg
Back Box Extension - std depth 4kg
Back Box Extension - extra depth 5kg
