ID3000 Series Installation & Commissioning Manual
Appendix 2
A2 - 2997-274-000-6, Issue 6
September 2009
Environmental:
Climatic classification: 3K5, (IEC 721-2-3)
Operating temperature: -5° C to +45° C,
(+5° C to +35° C recommended)
Humidity: 5% to 95% R.H.
Height above sea level: Maximum, 2000m
Panel sealing: IP 30, (EN 60529)
Vibration: EN 60068-2-6, 10-150Hz at
0.981ms
-2
(Meets the requirements
of EN 54-2/4)
EMC: Emissions: EN 61000-6-3
Immunity: EN 50130-4
Safety: EN 60950
Displays and Indications:
Alphanumeric display: 240 x 64 pixel, used to provide 6
lines of 40 characters each plus
graphical displays.
LED Status Indicators: FIRE, FAULT, DISABLEMENT,
TEST, POWER, PRE-ALARM,
SYSTEM FAULT, SOUNDER
FAULT/DISABLED, FIRE O/P
FAULT, FIRE O/P ACTIVE, DAY
MODE, DELAYS ACTIVE, NON-
FIRE ACTIVE.
Zone Indicators (optional): Individual FIRE and Fault
indicators for 64, 128, 192 or 256
zones (depending upon
configuration options).
Controls:
Dedicated flush push-buttons are provided for the following
functions:
MUTE BUZZER, EXTEND
DELAY, END DELAY/EVACUATE,
SILENCE/RESOUND, RESET,
DAY MODE, FIRE O/P DISABLE,
CHANGE TABS, ZONES IN
ALARM.
Additional pushbuttons for programming and selection of
software functions:
10-KEY NUMERIC KEY-PAD
KEYS
AND KEYS
KEY
