ID3000 Series Installation & Commissioning Manual
Installation Guide
4997-274-000-6, Issue 6
September 2009
2.1.4 Glossary of Icons
Throughout this Installation and Commissioning Manual
and other supplied user documentation a number of
simple icons are used, either on their own or together
with larger illustrations, to simplify a particular task or
process.
The following icons are used to advise or indicate:
a. DO follow the recommended procedure or method
b. DO NOT use this procedure or method
c. Inspection of an item or sub-assembly is required at
this point
d. Following a defined process meets the required
approval/inspection criteria or standards
e. Following a defined process does not meet the
required approval/inspection criteria or standards
f. Additional items to be considered
g. This icon placed next to a pushbutton requires you to
press it as part of a described process, such as isolate
or test, or while programming the panel. Where two or
more icons are used, a number may be placed on or
near each hand to indicate the order of selection: 1
coming before 2, etc.
h. Activity process step - flow arrow for single action or
iterative actions
i. Leader arrow - used with activity processes
j. Sounder operating
k. Sounder not-operating or silenced
l. Digital clock timer - press and hold the applicable
pushbutton for the time indicated
