ID3000 Series Installation & Commissioning Manual
Appendix 1
A1 - 4997-274-000-6, Issue 6
September 2009
1.1.6 Printer Faults
Printer Fault
Internal printer only. This fault may be an indication of a
paper jam or malfunction, no paper, or the printer may
be disconnected.
Note: The printer operation is only monitored if the printer
was functional at the last power-on.
1.1.7 Other Hardware Faults
a. Fault 47 - CPU/Display hardware fault
Communications fault between the CPU and the
display.
Action: Change the CPU PCB assembly (PN: 020-
569) and/or the Display PCB/Membrane Keypad (PN:
020-571-XXX).
b. Panel Key Stuck
Change the Display PCB/Membrane Keypad
(PN: 020-571-XXX).
c. Fault 48 - Base PCB/Expansion h/w fault
Change the Base PCB (PN: 020-568) or Extension
Chassis with Display Module Kit (PN: 020-559-XXX).
d. Aux. Output 1 Fault;
Aux. Output 2 Fault
This fault indicates a failure of the auxiliary drive
circuits and not the attached cables. Action: If the fault
is on either circuit, change the Base PCB (Kit
PN: 020-568).
e. Fault 71 - Config. needs Expansion Card
This fault message can only appear when ID3000
panels are networked with earlier compatible panels.
This message is not applicable to the ‘local’ ID3000
Series panel. In cases where it is applicable, an
Extension Chassis with Display Module Kit
(PN: 020-559-XXX) is required.
f. Fault 72 - Config. needs RS485 Card
Missing PCB - panel is configured for network but no
RS485 PCB is present. Fit Isolated RS485 Module
Kit (PN: 020-479) or change configuration.
g. Fault 73 - Config. needs RS232 Card
Missing PCB - panel is configured for 3rd-party
protocol but no RS232 PCB is present (does not apply
to other modes of the port). Fit Isolated RS232 Module
Kit (PN: 020-478) or change configuration.
h. Fault 74 - RS232\RS485\PRINTER Card displaced
An attempt has been made to remove one of these
items while the panel is powered up. Remove power
before proceeding.
