ID3000 Series Installation & Commissioning Manual
Appendix 3
A3 - 2997-274-000-6, Issue 6
September 2009
Loop Devices Supported
The following devices are supported:
Multi-criteria sensor:
IRX-751CTEM (SMART 4)
IRX-751TEM (SMART 3)
Other sensors:
a. CPX-551E (ION)
b. CPX-751E (ION - low profile)
c. SDX551E (OPT)
d. SDX-751 (OPT)
e. SDX-751EM
f. SDX-751-TEM (OptiPlex)
g. SDX-551THE
h. HPX-751E (HARSH)
i. IDX-751 (HAZARD)
j. FDX-551EM (Thermal - Type A1)
k. FDX-551HTEM (Thermal Hi-temp - Type BS)
l. FDX-551REM (Thermal - Type A1R)
m. LPX-751 (VIEW); FSL-751E (VIEW)
ZMX (Remote PSU):
a. ZMX-1
b. M710-CZ
c. MMX-2
MCP & Integral Isolators:
M500DKMI
10-Input Monitor Module:
MMX-10M (equivalent to 10 modules)
Monitor/MCP Modules:
a. M500KAC(GB/W)
b. M500DKM(R) M700KAC-FG, M700KACI-FG
c. MMX-1E
d. MMX-101E
e. MMX-102E
Control Modules:
a. CMX-2E
b. PS2/CMX (002-634-100); PS2/701
10-Output Control Module:
CMX-10RM (equivalent to 10 modules)
Externally-powered Sounders:
a. ANSE4/R/W
b. ABSE4
Wall Sounders - Loop Powered:
ANS4/R/W, AWS3/R/W
Base Sounders - Loop Powered:
ABS4, IBS3-WH, AWS32/X, AWS32/X-I
Base Relay - loop powered:
B524RE
Beam Detectors:
LPB500 (maximum of 4 per loop) LBP-700 /-700T
Monitor Modules:
M710 (MON,single)
M720 (MON, dual)
M721 (Dual I/P, single relay O/P)
MCX-55 (MON Card, 5 I/P & 5 O/P)
Control Modules:
M701 (single O/P + isolator)
M701-240 (single, mains relay module
+ isolator)
M701-240-DIN (single, mains relay
module + isolator + DIN rail mounting)
MRM-1 (single, mains relay module)
MRM-1/DIN (single, mains relay
module + DIN rail mounting)
Base Beacon:
ABB/W/C-I (+ Isolator)
Sounder:
ABS32/x, ABS32/x-I (+ Isolator)
Sounder Strobe:
ABSB32/X/C-I (+ Isolator)
Sounder Strobe:
AWSB32/X/R, AWSB32/X/R-I (+ Isolator)
ABSB32/X/C, ABSB32/X/C-I (+ Isolator)
Wall Strobe:
AWB/R, AWB/R-I (+ Isolator)
IDP-RMI - (Radio Interface)
IST200 - (Safety Translation Module)
Y72221 - Intrinsic Safety Galvanic isolator (for
HAZARD sensors)
Isolators:
ISO-X
M700X
B524IE
B524IEFT-1B/W
B524RTE
