ID3000/ID2000 Fire Panel Configuration Tool Manual
Network
6 - 7 997-291, Version 3.05
November 2010
c. FAULTS/AUX EV. refers to all possible faults
that can be detected by a panel, including
Power Supply Fault and System Fault. This
entry must also be enabled to allow the
control matrix in other panels to use AUX
device inputs and Pre-Alarm events.
d. TEST/DISABLEMT., when set, allows a walk
test to be set up at a panel other than that
at which the pushbutton is pressed. It also
allows zones to be enabled/disabled at a
remote panel, but only from the Master.
e. OTHER EVENTS covers events other than
those in b. - d. above; for example,
transmission to another panel to allow
recording on a printer installed at that panel.
Use caution when enabling this option;
increased network usage may cause
communications problems.
f. Fire in Zone(s). This can be done for all
zones (copied automatically into the
individual zone entries) or differently for each
of zones 1 to 64 (the all zones entry then
becomes invalid). The ID2000 may be
configured with up to 80 zones - the
distribution for zones 65 to 80 is set
automatically to that configured for zone 1.
BE AWARE OF THIS WHEN
CONFIGURING ZONE 1.
Zones 65 to 80 event distribution
is set automatically to that
configured for zone 1.
Opens/closes list of
stations for this
event
Summary display of
currently selected
event and station
Closes window
and saves
changes
Opens/closes list of
stations for ALL
events
Sets ALL events
to be transmitted
to all stations
To Next Page
