ID3000/ID2000 Fire Panel Configuration Tool Manual
Introduction
1 - 1 997-291, Version 3.05
November 2010
1 Introduction
The ID3000/ID2000 Fire Panel Configuration
Tool (PN: 020-558) allows the user to:
a. Configure panel settings, loop devices, the
Control Matrix and a network by using a PC
remote from the fire panel.
b. Receive the existing configuration from the
fire panel to the PC, and send a new or
edited configuration from the PC to the fire
panel.
c. Configure an IDR-6A repeater.
Throughout this manual the ID3000/ID2000 Fire
Panel Configuration Tool is referred to as ‘the
Tool’ and the fire panel as ‘the panel’.
Be aware that...
This manual is not intended to be a fire detection
system design guide and should only be used
by (or under the supervision of) a qualified
system design engineer.
It is assumed that the system has been
designed in accordance with the requirements
of EN54 Part 14, BS 5839 Part 1:1988 and
other local codes of practice that are applicable.
Some features of the panel may, if used
inappropriately, contravene the requirements of
EN54. This manual includes warnings (see
example opposite) where there is the possibility
of such an occurrence.
EN54-2: 13.7
Maximum of 512
Sensors and/or MCPs
per panel unless ELIBs
are used.
Cross-references (in bold
type) in this manual
include links. For example,
click on (see Section 4)
to go to that Section.
