ID3000/ID2000 Fire Panel Configuration Tool Manual
Control Matrix
4 - 3 997-291, Version 3.05
November 2010
f. If there is no entry of this type in the Control
Matrix, the actions in walk test are those
defined in the Control Matrix for the MCP
that is operated. With or without a walk test
Control Matrix entry, actions apply only at
the local panel except in the case where
there is a walk test Control Matrix entry and
an ID
2
net.
g. Used to: (i) transfer the output of one Control
Matrix entry to the input of another, when
both entries have a delay configured, (ii)
allow logic combinations (Section 4.1.5). Up
to 128 separate transfer flags can be used.
h. TRUE allows output(s) to be disabled/
enabled under control of a Time-Of-Day
(TOD) program. To disable when the TOD
program is not active (Control Matrix action
active when TOD period is not), use a
Control Matrix entry with input statement
‘TRUE’ and output statement consisting of
a TOD program and the output(s) to be
disabled/enabled.
Note: If output(s) are disabled/enabled by other
means during the TOD-initiated period,
the TOD-driven state is re-asserted by
any subsequent TOD status change (e.g
a sensor undergoes a sensitivity change)
or at the beginning and end of the
configured period.
i On a network, the panel from which this input
is activated can be specified.
EN54-2: 9.1.2
Disablement and
re-enablement MUST be
a manual operation
