NFN Gateway Configuration Configuration PC Preparation
30 NFN Gateway Installation & Operation Manual - P/N: 52306:Rev: D 06/01/07
3.2 Configuration PC Preparation
A Configuration PC is defined as a PC that has the NFN Config Tool installed on it and it is able to
establish an IP connection with the NFN Gateway.
3.2.1 Install the NFN Config Tool on the Configuration PC
You need to install the entire ONYXWorks
®
Workstation software application on the Configuration
PC (90 MB disk space). The CD-ROM automatically starts if your Configuration PC is setup to
start CD-ROMs automatically.
3.2.2 Connect the Configuration PC to the NFN Gateway
Use one of the following methods to connect the Configuration PC to the NFN Gateway.
• If the Configuration PC is on your IP network then you already have connected it to the NFN
Gateway if you performed the “IP Cable Connections” on page 24.
Therefore you need to “Add the IP Subnet of the NFN Gateway into the Configuration PC” on
page 32.
• If you are going to use a PC and directly connect it to the gateway then you need to perform a
“Direct Connection to the Gateway PC Board” on page 31.
NOTE: You must have completed the installation of the NFN Gateway before you proceed with
this preparation (refer to “NFN Gateway Embedded Installation” on page 17).
NOTE: A direct connection requires that a cross over Ethernet cable to be made or purchased
by the customer.
