PW-6000 Installation
Product Overview
PW-6000 (PW6K1IC) Installation and Configuration Guide, Document 800-00005V3 9
2.1 PW-6000 and PW-5000
• The PW-6000 controller configuration and operation is similar to the PW-5000
controller; both use the Pro-Watch at the front end.
Note: The PW6K1IC controller is compatible with the following Honeywell modules:
PW6K1R2, PW6K1IN, and PW6K1OUT. The PW6K1IC is also compatible with the
following PW5K assemblies but they have not been evaluated by UL for S-319:
PW5K1R1, PW5K1R2, PW5K1IN, PW5K1OUT.
2.2 Port Settings
• Port 0 provides the host-embedded Ethernet interface.
• Port 1 is for RS-232 or RS-485 2-wire serial interface connections. An
optional Lantronix CoBox-Micro interface daughter board
(10Base-T/100Base-TX) is also supported on Port 1.
• Ports 2 and 3 are for RS-485 2-wire downstream support for connecting 32
I/O devices. Note that the I/O communications must be mapped differently in
Pro-Watch, according to the following table:
See Table 1 'PW-6000 Jumper Settings' on page 11 for more information on how to
configure the port settings.
2.3 Other
• An on-board real time clock maintains the date and time, taking into account
leap year and accounting for global time zones and daylight savings time
changes.
• The database for the system configuration and card holders are stored in
FLASH memory.
• The event log buffer is stored in battery-backed memory.
• Configuration data and event/status reports are communicated to the host via
on-board 10-BaseT/100Base-TX Ethernet port or Port 1.
• Transactions are stored in 1 MB of battery-backed SRAM. The maximum
number of transactions stored while the host is offline is 50,000.
• Cards are stored in Flash memory and read into DRAM when the board is
powered up. The amount of storage available for cards and biometric records is
15 MB. The maximum number of cards depends on the card record database
configuration, but the number is approximately 300,000. This maximum is
dependent on how the card is configured with more space per card used with
longer card number, more clearance codes, and so on.
PW-6000 Port Pro-Watch Port
24
36
