PW-6000 Installation
Notices
Note: Not Evaluated by UL for fire, life safety, or burglary applications.
The earth ground is connected at the factory and should not be removed.
Do Not Connect To A Receptacle Controlled By A Switch.
Replacement 3 volt lithium coin cell must be one of the following:
Rayovac: BR2325 or BR2335-B
All interconnecting wire must be UL/ULC Listed, rated and suitable for the use.
The battery leads and primary AC main power wiring is non-power limited. This
wiring must be separated from all other wiring by at least 0.25" and cannot be
installed in the same conduit as any other power limited wiring.
The system must be configured to activate an alarm or trouble signal. Failure to do so
will not allow the access function to operate in the event of a tamper.
1.3 Damage During Shipment
Caution: IF ANY DAMAGE TO THE SHIPMENT IS NOTICED, A CLAIM MUST
BE FILED WITH THE COMMERCIAL CARRIER RESPONSIBLE FOR THE
DAMAGE.
ATTENTION: SI L'EQUIPEMENT A SUBI DES DOMMAGES LORS DE SON
TRANSPORT, ADRESSER UNE RECLAMATION AU TRANSPORTEUR
RESPONSABLE.
1.4 Electro Static Discharge
Caution: Electro-static discharge (ESD) can damage CMOS integrated circuits and
modules.
To prevent damage always follow these procedures:
• Use static shield packaging and containers to transport all electronic
components, including completed reader assemblies.
• Handle all ESD sensitive components at an approved static-controlled
workstation. These workstations consist of a desk mat, floor mat and an ESD
wrist strap. Workstations are available from various vendors.
ATTENTION: Des décharges électrostatiques peuvent endommager les modules et
circuits intégrés CMOS.
PW5K2ENC1 and PW5K2ENC2 800-06952
PW5K1ENC3 800-06955V1
PW5K2ENC5 800-08421
PW6K2E2PS 800-08279V3
Assembly Number Installation Manual Part Number
