PW-6000 Installation
Setting Up the PW-6000 Hardware
PW-6000 (PW6K1IC) Installation and Configuration Guide, Document 800-00005V3 13
The PW-6000 DIP switches need to be set twice:
1. Configure the S4-S3-S2-S1 DIP switches to off-off-on-off to set the default
TCP/IP address to 192.168.0.251.
2. Apply power to the panel to set the IP address.
3. Change the S4-S3-S2-S1 combination to off-off-off-on.(DIP switch 1 is “read
on the fly”). This sets the login to the default user ID (“admin”) and password
(“password”) for Ethernet communications.
4. Create users. See 'User Configuration' on page 26 for instructions.
5. Set the S4-S3-S2-S1 combination to off-off-off-off.
6. Configure the host port for TCP/IP and/or Serial communications. See 'Host
Port' on page 21 for instructions. This will enable both TCP/IP and serial
hardware networking when you log in again.
