22 www.honeywell.com
PW-6000 Installation
System Configuration via Web Interface
1. From PW6000 Communication Address drop-down list, select one of the eight
(0 to 7) available communication addresses for the PW-6000 board.
Note: In the previous panels, this selection was made manually by setting the
DIP switches.
2. For the Primary Host Port, make the following selections:
a. Connection Type. Select IP Server (the standard connection type), so
that the Pro-Watch Host will poll the PW-6000 panel. The panel does
not currently support the IP Client option, which would cause the
PW-6000 panel to poll the Pro-Watch Host and the Host to reply to the
panel.
b. Data Security. Select one of the following:
–None
– Password/AES from the drop-down list. If you select
Password/AES, communications between the Pro-Watch Host
and the PW-6000 panel are encrypted. Note that encryption must
be enabled in Pro-Watch for the appropriate Pro-Watch channel.
See Chapter 7, “Hardware Configuration,” in the Pro-Watch
Guide for channel encryption instructions.
c. Port Number. Enter the port number through which the host computer
can communicate with the PW-6000 board.
d. Select either Allow All or the Authorized IP Address Required option
button.
– Allow All, as the label suggests, allows all IP addresses to
communicate with the PW-6000. Select this option for web page
browser access.
– If you select the Authorized IP Address Required option, also
enter in the Authorized IP Addresses fields all the IP addresses
that would be allowed to communicate with the PW-6000. Use
this option only for Host communication.
3. For the Alternate Host Port, make the following selections:
a. Connection Type. Select one of the following values from the
drop-down list: IP Server, Serial-RS232, Serial-RS485,
Serial-Modem, Serial-CoBox. Note that the IPClient option is listed,
but it is not supported by the panel and should not be selected.
b. Data Security. Select one of the following values from the drop-down
list: None, Password/no AES, Password/AES.
c. Select a Baud Rate from the drop-down list.
d. Select a Flow Control from the drop-down list.
4. Click
OK.
