Honeywell ScanPal 5100 User Manual

2 - 4
Desktop
Note: You can access the Desktop any time by selecting the Change Views icon in the command bar and selecting
Desktop on the popup menu.
Command Bar Icons
The command bar, located at the bottom of application screens, provides access to many system
functions and programs.
Icon Meaning
Opens the Start menu.
Changes views between open applications or returns to the Desktop.
Accesses the Bluetooth radio. Select this icon to open the Bluetooth Handler (see page 8-1).
Shows signal strength of WiFi radio. (A red X indicates the terminal is not currently associated to
an access point.)
Indicates that the USB communication cable is connected. Select to display USB status window.
Indicates the status of battery power. Select to open the Power control panel setting.
When this icon shows a red power plug, it indicates the device is using external power.
Displays the current time. Select to change the time and date.
Select to
change views

Honeywell ScanPal 5100 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.128 GB
Internal memory	0.064 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	PXA 300
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows CE 5.0
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3300 mAh
Battery life (max)	8 h
Product color	Black, Grey
International Protection (IP) code	IP54
Keypad number of keys	28

Weight and Dimensions

Depth	57 mm
Width	157 mm
Height	41 mm
Weight	231 g
