Honeywell ScanPal 5100 User Manual

5 - 1
5
Using the Laser Engine
Overview
If your terminal is equipped with a laser engine, you will be able to read all popular 1D bar codes.
Available Laser Engines
ScanPal 5100s are equipped with 4813 1D laser engines.
Depth of Field
4813 Standard Range
*Data characterized at 23°C and 0 lux ambient light.
Supported Bar Code Symbologies
5.2 mil
Linear
7.5 mil
Linear
10.4 mil
EAN 13
10.4 mil
Code 128
13 mil
UPC
19.5 mil
UPC
Working
Range*
(.013cm) (.019cm) (.026cm) (.026cm) (.033cm) (.049cm)
Near 2.8 in.
(7.0cm)
2.2 in.
(5.7cm)
2.0 in.
(5.0cm)
2.0 in.
(5.0cm)
2.0 in.
(5.0cm)
3.0 in.
(7.5cm)
Far 3.7 in.
(9.5cm)
6.7 in.
(17.1cm)
10.0 in.
(25.4cm)
8.3 in.
(21.0cm)
10.0 in.
(25.4cm)
11.8 in.
(30.0cm)
Symbology Type Symbology Name
1D Symbologies Codabar
Code 3 of 9
Code 11
Code 93
Code 128
EAN-8
EAN-13
GS1 Databar
Interleaved 2 of 5
Matrix 2 of 5
Plessey
Standard 2 of 5
Hongkong 2 of 5
NEC 2 of 5
Straight 2 of 5 IATA 13 Digit
Straight 2 of 5 IATA 15 Digit
Telepen
Trioptic Code
GS1-128
UPC-A and UPC-E

Honeywell ScanPal 5100 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.128 GB
Internal memory	0.064 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	PXA 300
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows CE 5.0
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3300 mAh
Battery life (max)	8 h
Product color	Black, Grey
International Protection (IP) code	IP54
Keypad number of keys	28

Weight and Dimensions

Depth	57 mm
Width	157 mm
Height	41 mm
Weight	231 g
