Honeywell ScanPal 5100

6 - 1
6
Using the Image Engine
Overview
If your terminal is equipped with a image engine, it houses a compact image engine using Adaptus
™
Imaging Technology that instantly reads all popular 1D and 2D bar codes and supports omni-directional
aiming and decoding. The image engine can also capture digital images, such as signatures and pictures.
Available Image Engines
ScanPal 5100s are equipped with 5300 Standard Range (5300SR) image engines.
Depth of Field
5300 Standard Range (5300SR)
*Data characterized at 23°C and 0 lux ambient light.
8.3 mil
Linear
10 mil
PDF417
13 mil
UPC
15 mil
Data Matrix
15 mil
QR
35 mil
MaxiCode
Working
Range*
(.020cm) (.025cm) (.033cm) (.038cm) (.038cm) (.089cm)
Near 3.5 in.
(8.9cm)
3.1 in.
(7.9cm)
2.1 in.
(5.3cm)
2.3 in.
5.8cm)
3.1 in.
(7.9cm)
2.0 in.
(5.1cm)
Far 7.6 in.
(19.3cm)
9 in.
(22.9cm)
13.2 in.
(33.5cm)
10.2 in.
(25.9cm)
8.8 in.
(22.4cm)
13.0 in.
(33cm)
