Honeywell ScanPal 5100 User Manual

9 - 6
Technical Specifications
Structural
Dimensions 5.3 in. high X 4.5 in. wide X 3.1 in. deep (13.5 cm. X 11.4 cm. X 7.9 cm.)
Weight 11.0 oz. (313g)
Material Polycarbonate
Color Black
Environmental
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to 158°F (-20° to +70°C)
Charging Temperature 32° to 104°F (0° to 40°C)
Electrical Static Discharge Air: ± 15k Vdc
Direct: ± 8k Vdc
Humidity 90% relative humidity (non-condensing)
Power Supply
Input (Universal)
(from the power source)
100–240 Volts, 0.3 A
50–60Hz
Included with ScanPal 5100 terminal
Output (to the base) 5 Volts DC, 2.0 A
Charging
Standard Charge Standard Capacity: 2200mAh - four hours
Extended Capacity: 3300mAh - six hours
Max Charging Current 2A Max
Standby Current <100mA
Status LED Green: charged
Red: charging
Communication
Interface USB Mini-B Male connector supports data transmission of up to12 Mbps
OR
Standard DB9 serial connector supports data transmission up to 115 Kbps
Agency Approvals
Power Supply: UL listed
TUV licensed
Charging: CCC
Fire Retardant: UL 94V-O

Honeywell ScanPal 5100 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.128 GB
Internal memory	0.064 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	PXA 300
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows CE 5.0
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3300 mAh
Battery life (max)	8 h
Product color	Black, Grey
International Protection (IP) code	IP54
Keypad number of keys	28

Weight and Dimensions

Depth	57 mm
Width	157 mm
Height	41 mm
Weight	231 g
