Honeywell ScanPal 5100 User Manual

4 - 1
4
Using the Keypad
Overview
Navigation Keys
Located in the center of the keypad for easy access with either hand, the navigation keys enable you to
move the cursor up and down lines and from character to character.
Basic Keys
Name Function
ALPHA Toggles the keypad between alpha (upper and lowercase), numeric, and mouse
pointer modes. Indicator changes accordingly on the command bar.
Backspace Backspace moves the cursor back one space.
If you are typing text, a character is deleted each time you press the backspace
key.
Control Modifies the next key pressed to type specific characters.
Escape Cancels an action.
Enter Performs the same function as the Enter key on a workstation.
Power Suspends and resumes the terminal.
Scan Activates the image engine to scan a bar code or take an image, if applicable.
Space Moves the cursor one space forward.
If you are typing text, it moves the text one space forward as well.
Navigation
keys
Power key

Honeywell ScanPal 5100 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.128 GB
Internal memory	0.064 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	PXA 300
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows CE 5.0
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3300 mAh
Battery life (max)	8 h
Product color	Black, Grey
International Protection (IP) code	IP54
Keypad number of keys	28

Weight and Dimensions

Depth	57 mm
Width	157 mm
Height	41 mm
Weight	231 g
