Honeywell ScanPal 5100 User Manual

10 - 4
Technical Specifications
Structural
Dimensions 7.3 in. long X 3.7 in. wide X 2.4 in. high
(18.5 cm. X 9.4 cm. X 6.1 cm.)
Weight 11.5 oz. (325g)
Material Case: Polycarbonate
Color: Black
Capacity Supports up to four Li-ion battery packs
Environmental
Operating Temperature 14° to 122°F (-10° to 50°C)
Storage Temperature -4° to +158°F (-20° to +70°C)
Charging Temperature 32° to 104°F (0° to 40°C)
Electrical Static
Discharge
Air: ± 15k Vdc
Direct: ± 8k Vdc
Humidity 90% relative humidity (non-condensing)
Power Supply
Input (Universal) 100V-240V, 1.2 A
50-60Hz
Included
Output 5Volts DC, 4.0 A
Charging
Standard Charge Standard Capacity 2200mAh - four hours
Extended Capacity 3300mAh - six hours
Status LEDs Green: charged
Red: charging
Agency Approvals
Power Supply UL listed
TUV licensed
Power Supply compliant to FCC part 15, Class B
Charging CE Marking
CISPR Pub 22
Fire Retardant UL94 V-0

Honeywell ScanPal 5100 Specifications

General

Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	-
Flash memory	0.128 GB
Internal memory	0.064 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	PXA 300
Processor frequency	0.624 GHz
GPS (satellite)	No
Operating system installed	Windows CE 5.0
Wi-Fi standards	802.11b, 802.11g
Bluetooth version	2.0+EDR
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	3300 mAh
Battery life (max)	8 h
Product color	Black, Grey
International Protection (IP) code	IP54
Keypad number of keys	28

Weight and Dimensions

Depth	57 mm
Width	157 mm
Height	41 mm
Weight	231 g
