2.2 Index
The meter is equipped with the index MI-2.
2.3. Temperature test points
Temperature sensors can be inserted into a thermowell for measuring the
gas temperature in the gas meter housing. Up to two thermowells are
available for this on turbine meters SM-RI as an option (depending on the
meter size). There are no temperature test points on quantometers Q75.
Property:
MI
-
2
Mechanical roller index, 8
-
digit
•
2 x mechanical roller index, 8
-
digit
1)
•
Index, can be turned through 355°
•
Protection class IP67
•
45° reading
•
Vertical reading
•
Connection for external pulse generator IN
-
Sxx/IN-Wxx
•
Suitable for internal
pulse generator IN
-
Cxx
-
S1xR internal reed contact pulse generator
-
Optional: mechanical index drive
•
Optional: desiccant cartridge
•
Optional: ENCODER
•
Fig. 3 | Index MI-2
Fig. 4 | Temperature and pressure test points
Temperature test point
Pressure test point
Table 1 | Properties of index MI
-
2
1)
One index is covered depending on the installation
position.
