Honeywell
73024521a
© Elster GmbH | All rights reserved. Subject to modification
29
English
Pressure loss and pulse value
SM-RI-X/Q75
Nominal size
Meter size
Pressure loss
of SM-RI-X
Pressure loss
of Q75
LF
MF
HF
MI-1
MI-2
[mbar]*
[mbar]*
[1/m³]**
[Hz at Q
max
]
[Hz at Q
max
]
DN 50
2"
G40 3 - 10/100
135 74 1690***
G65 6.5 - 10/100
210 116 2600***
DN 80
3"
G100 3 - 1/10 105 58 1280***
G160 8 - 1/10 160 88 2000***
G250 21 - 1/10 150 83 1800***
DN 100
4"
G160 2 - 1/10 100 55 110***
G250 5 - 1/10 160 88 1760***
G400 13 - 1/10 145 80 1570***
DN 150
6"
G400 3.5 - 1/10 150 83 1180
G650 7 - 1/10 130 72 1060
G1000
16.5 - 1/10 210 116 1700
DN 200
8"
G650 1.5 1.5 0.1/1 55 30 770
G100 3 2.5 0.1/1 85 47 1180
G1600
8 5.5 0.1/1 83 46 1060
DN 250
10"
G1000
1.5 1.5 0.1/1 88 49 825
G1600
4.5 3.5 0.1/1 140 77 1320
G2500
10 8.5 0.1/1 125 69 1200
DN 300
12"
G1600
1.5 1.5 0.1/1 48 26 810
G2500
5 4 0.1/1 76 42 1270
G4000
14 9 0.1/1 70 39 1175
DN 400
16"
G2500
1.5 1.5 0.1/1 760 88 660
G4000
5 4 0.1/1 255 141 1055
G6500
13 9 0.1/1 220 121 890
DN 500
20"
G4000
1.5 1.5 0.1/1 130 72 530
G6500
6.5 4 0.1/1 210 116 865
G10000
15 9 0.1/1 190 105 770
DN 600
24"
G6500
1.5 1.5 0.01/0.1
48 26 470
G10000
5 4 0.01/0.1
75 41 720
G16000
10.5 9 0.01/0.1
68 38 650
Table 8 | Pressure loss and pulse value
*
At Q
max
natural gas = 0.8 kg/m³
**
Pulses with 1 or 10 magnets
***
HF pulse sensor on turbine wheel not available
