74 Solaris 7980g User Guide
Data Format Editor Commands
When working with the Data Format Editor, a virtual cursor is moved along your
input data string. The following commands are used to both move this cursor to
different positions, and to select, replace, and insert data into the final output.
Send Commands
Send all characters
F1 Include in the output message all of the characters from the input message, starting
from current cursor position, followed by an insert character. Syntax = F1xx where xx
stands for the insert character’s hex value for its ASCII code. Refer to the ASCII
Conversion Chart (Code Page 1252), beginning on page 224 for decimal, hex and
character codes.
Send a number of characters
F2 Include in the output message a number of characters followed by an insert
character. Start from the current cursor position and continue for “nn” characters or
through the last character in the input message, followed by character “xx.” Syntax
= F2nnxx where nn stands for the numeric value (00-99) for the number of
characters, and xx stands for the insert character’s hex value for its ASCII code.
Refer to the ASCII Conversion Chart (Code Page 1252), beginning on page 224 for
decimal, hex and character codes.
Terminal ID Table
Terminal Model(s) Terminal ID
USB PC keyboard (HID)
124
Mac Keyboard
125
PC Keyboard (Japanese)
134
Serial (COM driver required)
130
HID POS
131
USB SurePOS Handheld
128
USB SurePOS Tabletop
129
Serial RS232 TTL
000
RS232 True
000
RS485 (IBM-HHBCR 1+2, 46xx)
051
Keyboard PS2 compatibles
003
